KILLARK XCS-0MMR3 by Killark, a Hubbell affiliate
- Part Number: XCS-0MMR3
- UPC: 00783936890401
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
KLRK XCS-0MMR3 RED PUSH=PULL MAINT NO/NC
Specifications
Details
Category:
Lighting Controls
Electrical Category:
Conduit and Fittings
Electrical Subcategory:
Conduit Fittings
Action:
SP
Actuator:
Maintained Pushbutton
Amperage Rating:
10
Application:
Hazardous locations due to the presence of flammable gases or vapors, combustible dusts, or easily ignitable fiber or flyings. Installations at petroleum refineries, chemical and petrochemical plants, and other processing or storage facilities where simil
Brand Name:
KILLARK
Color:
Red
Contact Configuration:
1-NO/1-NC
Contact Rating:
60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;
Country Of Origin:
US
Environmental Conditions:
Hazardous locations
Lead Time:
15.000 WK
Material:
Copper-free aluminum
Number Of Poles:
1
Size:
5.56 in x 4 in x 5.63 in
Spec Sheet:
Special Features:
Killark XCS SERIES CONTROL STATION Control Stations provide control solutions in hazardous location areas to supply; START/STOP Motor Functions, LED Pilot Light Indications and more. Utilized in Class 1 Division 1 & 2, Class 1 Zone 1 & 2 areas for indoor
Standard:
UL, CSA
Type:
Aluminum Cover With Push-Pull Button
UNSPSC:
39122216
Voltage Rating:
600 VAC maximum
Warranty Link:
Weight:
1.400 L
Manufactured By:
Killark, a Hubbell affiliate
