RECPT, SB, 50A 125/250V, FLNG, WH W/PLT by Hubbell Wiring Device-Kellems
- Part Number: RR450WIPCN
- UPC: 00883778301865
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
TradeSelect, Straight Blade, Single Panel Mount Receptacle, 50A 125/250V, 3-Pole 4-Wire Grounding, 14-50R, Black, With Plate
Specifications
Details
Electrical Category:
Electrical Distribution Equipment
Lugs Plugs And Connectors
Electrical Subcategory:
Receptacles
Receptacle
Amperage Rating:
50
Application:
Residential Grade
Brand Name:
WIRING DEVICE-KELLEMS
Color:
White
Connection:
Screw Terminals
Country Of Origin:
CN
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Installation Link:
Line Drawing Link:
Material:
Thermoplastic
Mounting:
Screw Mount
NEMA Rating:
14-50R
Number Of Poles:
3-Pole
Number Of Wires:
4-Wire Grounding
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
Phase:
Single Phase
Size:
Standard Sized Product
Spec Sheet:
Special Features:
Comer With Plate
Standard:
NEMA WD1 and WD5, UL 498
Sub Brand:
Straight Blade Devices
Tech Drawing Link:
Type:
Flanged Single
UNSPSC:
39121406
Voltage Rating:
125/250
Warranty Link:
Wattage:
12,500
Weight:
.400 L
Wire Size:
#10 AWG Min #6 AWG Max
Manufactured By:
Hubbell Wiring Device-Kellems
