15A/120VAC 2P CIRCUIT BREAKER, 1PH by Hubbell Wiring Device-Kellems
- Part Number: GFSMCB120152P
- UPC: 00783585692302
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (14)
Product Overview
Power Protection Product, GFCI Circuit Breakers, Industrial, Double Pole, 15A 120V AC, GFCI Circuit Breaker Sensing Modules, 4-6 mA Trip Level, Black
Specifications
Details
Electrical Category:
Electrical Distribution Equipment
Fuses Relays And Circuit Breakers
Electrical Subcategory:
Breakers
Circuit Breakers And Accessories
Actuator:
Toggle
Application:
Heavy Duty Industrial Commercial
Auxiliary Contacts:
None
Brand Name:
WIRING DEVICE-KELLEMS
Connection:
Terminal Screws
Country Of Origin:
MX
Current Rating:
15
Enclosure:
None
Environmental Conditions:
NEMA 4X with Supplied Gasket
Frame:
Standard
Frequency Rating:
60
Height:
3
Installation Link:
Interrupt Rating:
10,000
Length:
3.00"
Line Drawing Link:
Load Rating:
80% of Full Rating Continuous A
Material:
Composite
Number Of Phases:
Single Phase
Number Of Poles:
2-Pole
Operating Temperature:
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
Special Features:
Standard Product
Standard:
UL 2201 and UL 943
Sub Brand:
GFCI Sensing Module and Breakers
Tech Drawing Link:
Trip Range:
4 to 6 mA in
Trip Type:
.025 Seconds
Type:
Circuit Breaker
UNSPSC:
39121601
Voltage Rating:
120
Weight:
.450 L
Width:
1.74
Manufactured By:
Hubbell Wiring Device-Kellems
